| VIBRATORY FINISHING MACHINE |
VB-D
BI-ARC SHAPE VIBRATORY FINISHING MACHINE.
Features:
Suitable for polishing aluminum, aluminum
alloys, iron, white iron, zinc, and magnesium alloys.
With the arc-shape body, this model allows workpieces to
easily move and turn inside the barrel.
Usages:
Suitable for long workpieces like bicycle parts,
forged items, and vases, and for grinding powder blocks
into a fine powder.
| VIBRATORY FINISHING MACHINE(VB-D) | ||||||
|---|---|---|---|---|---|---|
| Model | Weight (Kg) | Motor (Hp) | Watt (Kw) | Width (mm) | Fill Volume (Kg) | Poles (P) |
| VB-65 | 233 | 2 | 1.5 | ψ765 X835H | 100 | 4P |
| VB-150 | 387 | 3 | 2.25 | ψ950 X 999H | 380 | 4P |
| VB-250 | 578 | 5 | 3.75 | ψ1122 X 980H | 650 | 4P |
| VB-350 | 720 | 7.5 | 3.75 | ψ1345 X 940H | 800 | 4P |
| VB-500 | 1010 | 10 | 3.75 | ψ1443 X 1125H | 1000 | 4P |
| VB-750 | 1441 | 12 | 3.75 | ψ1704 X 1312H | 1200 | 4P |
.jpg)
| VIBRATION MACHINE APPEARANCE DIMENSIONS(SUBJECT TO PHYSICAL MACHINERY) | ||||||
|---|---|---|---|---|---|---|
| MACHINE SIZE | A | B | C | D | E | F |
| 65 | 765 | -- | 935 | 370 | 200 | 260 |
| 100 | 906 | 99 | 810 | 334 | 216 | 310 |
| 150 | 1045 | 1035 | 825 | 355 | 280 | 325 |
| 250 | 1200 | 1260 | 990 | 455 | 300 | 400 |
| 350 | 1340 | 1330 | 1025 | 550 | 320 | 450 |
| 500 | 1560 | 1360 | 1090 | 576 | 400 | 470 |
| 750 | 1730 | 1770 | 1400 | 770 | 410 | 550 |
| 1000 | 1880 | 1500 | 1300 | 810 | 445 | 670 |
.jpg)
