| TUMBLER ROTATION MACHINE |
IO/IH
TILTABLE TYPE HEXAGON (OCTAGON) TUMBLER ROTATION GRINDING MACHINES
Features:
Free speed adjustment.
Manual-control barrel dumping.
Easy and safe operatio
Usages :
Suitable for small workpieces like ornaments.
For eliminating black membrane, fine grinding, deburring, and chamfering.
| LNCLINED TYPE HEXAGON (OCTAGON) TUMBLER ROTATION GRINDING MACHINES(IO/IH) | ||||||
|---|---|---|---|---|---|---|
| Model | Weight (Kg) | Motor (Hp) | Watt (Kw) | Width (mm) | Fill Volume (Kg) | R.P.M |
| IH15-A | 100 | 0.5 | 0.37 | 1045 x 1050 x 1470 | 15L x 80% | 15~40 |
| IH25-A | 150 | 1 | 0.75 | 1070 x 1050 x 1470 | 25L x 80% | 15~40 |
| IH50-A | 250 | 2 | 1.5 | 1145 x 1050 x 1550 | 50L x 80% | 15~40 |
